The recommended torque range for standard low carbon steel # 6-32 screws is 6 - 10 in-lbs. Refer to the quick reference guide that came with the board for the location of the screw mounting holes.
DESKTOP BOARD DH61BE INSTALL
If you have a BTX-based board and chassis, be sure to first install the SRM that comes with the BTX chassis, if not already pre-installed.
Secure the board to the chassis using the screws provided with the chassis.
DESKTOP BOARD DH61BE MANUAL
Refer to your chassis manual for specific instructions on installing and removing the desktop board. Press the shield into place so that it fits tightly and securely.
Place the shield inside the chassis as shown in the figure below.
Install the I/O shield before installing the board in the chassis. The board comes with an I/O shield that is used to block radio frequency transmissions, necessary to pass emissions (EMI) certification testing, protect internal components from dust and foreign objects, and promote correct airflow within the chassis. Connect devices to back panel connectors.Install add-in PCI Express* graphics (optional).Install IDE devices (drives / DVD / CDROM).Install the processor fan heatsink or thermal module.The basic integration sequence is as follows: The following is a step-by-step integration guide that provides basic information needed to correctly build a PC based on an Intel® Desktop Board. If such a workstation is not available, wear an antistatic wrist strap or touch the surface of the antistatic package before handling the board. Install the board at an ESD-controlled workstation. Electrostatic discharge (ESD) can damage desktop board components.Some circuitry on the desktop board can continue to operate even though the front panel power switch is off. Failure to do this can result in personal injury or equipment damage. Disconnect the desktop board's power supply from its AC power source before you connect or disconnect cables, or install or remove any board components.Keyboard wake up, RTC (real-time clock) wake up, suspend to RAM (STR), wake on LAN (WOL), mouse wake up, wake on PCI device, wake on USB portĬhassis intrusion detection, Intel Turbo Boost Technology 2. Hyper-Threading Technology, ACPI 3.0b support, SMBIOS 2.5 support, Wfm support
DESKTOP BOARD DH61BE SOFTWARE
"Compatible with Windows 7" software and devices carry Microsoft’s assurance that these products have passed tests for compatibility and reliability with 32-bit and 64-bit Windows 7.ĬISPR 22 Class B, BSMI CNS 13438 Class B, EN 60950, IEC 60950, EN55024, EN55022 Class B, CB, ICES-003 Class B, FCC Part 15 B, EMC, UL 1950 Third Edition, RoHS, Lead-Free, CSA C22.2 No. Intel Express Installer, Intel Desktop Utilities, Laplink PCmover Express, ESET Smart Security 4 (1 year license)
DESKTOP BOARD DH61BE SERIAL
SATA-600 -connectors: 2 x 7pin Serial ATA - 2 devices - RAID 0 / RAID 1 / RAID 10 / RAID 5 ¦ SATA-300 -connectors: 4 x 7pin Serial ATA - 4 devices - RAID 0 / RAID 1 / RAID 10 / RAID 5ġ x PS/2 keyboard / mouse ¦ 1 x VGA ¦ 1 x DVI-D ¦ 2 x USB 2.0 ¦ 1 x LAN (Gigabit Ethernet) ¦ 1 x audio line-in - mini-jack ¦ 1 x audio line-out - mini-jack ¦ 1 x microphone - mini-jack ¦ 1 x audio line-out (center/subwoofer) - mini-jack ¦ 1 x audio line-out (rear) - mini-jack ¦ 1 x TOSLINK ¦ 2 x USB 3.0Ĥ-pin ATX12V connector, 24-pin main power connectorĢ x Serial ATA cable ¦ 1 x DVI-VGA adapter Intel TDSourcing Desktop Board DH61BE - Classic Series - motherboard - micro ATX - LGA1155 Socket - H61Ģ x USB 3.0 + 2 x USB 2.0 + (8 x USB 2.0 via headers)ġ x CPU ¦ 2 x DIMM 240-pin ¦ 1 x PCIe 2.0 x16 ¦ 2 x PCIe 2.0 x1 ¦ 1 x PCI
